Version 9.1.2.0 (28/01/2023)
- Presentation video: https://www.youtube.com/watch?v=XU0bjNPeRHk
- New Free 3D layers for easier swallow tails and beak nose and much more possibilities!
- Definition of deck rail point on slices for 3D layers with "Map on extended rail" option.
- Distinction between Shape and Structure 3D layers.
Structures have their density and elastic modulus defined
and are note taken into account for plugs positioning.
- Weight of plugs.
- List of 3D layers displayed in a collapsible group,
- Display/hide, or activate/deactivate 3D layers all at once.
- Measurement bars with labels displayed in the curves list.
- Export slices with 3D layers full scale or with scale factor in Pdf.
- Sectional 3D view.
- Plugs cut in CNC mode with possibility to set different Y Z margins for each.
- Upward cut option for shifted stringers
- And some small corrections of course...
Login
to obtain the DOWNLOAD link
Version 9.1.1.8 (03/08/2022)
- Presentation video: https://www.youtube.com/watch?v=u3pFHUe8hc4
- Fonction Add/remove thickness all over
- Fonction Flip deck/bot
- Mold fonction with closed tips
- Improved IGES export with closed tips
- Display curvature radius value of the curves in the tracing
- Display average and max cord, aspect ratio for foil and fin designs
- Improved NACA profile generator, with trailing edge thickness
- Hollow wooden plan with triangle, rounded corner holes, tool diameter, 4 stripes rail
- Possibility to change the cutting order of the plugs
- Stringer roughing with dz steps and final dZ
- Shape3d Cloud beta!
- And some small corrections of course...
Login
to obtain the DOWNLOAD link
Version 9.1.1.6 (28/12/2021)
- Presentation video: https://www.youtube.com/watch?v=u7SET-zAEtM
- NACA profile generator
- Import profile from .dat or .csv file
- Export to Xflr5 to compute foil Lift and Drag
- Easier asymmetric design
- Box plugs with rounded corner
- Cylindrical plug with circular or ovoid shape
- Plan with vertical display
- Print as PDF on Mac
- File protection Resize Only
- File protection No Cutting Path except one Cutting Center
- Improved Stock Wizard
- Disk motor with arm and box dimensions,
better blank touching security
- Multi-tool CNC with selection of a different tool for each 3D layers
- Definition of groups of 3D layers to cut selected 3D layers at the same time
- And alot of miscellaneous improvements
and corrections!
WARNING make sure you didn't place your files in the Shape3d application folder!
If they are, move them outside before doing the update!
Login
to obtain the DOWNLOAD link
Version 9.1.1.4 (04/06/2021)
- Presentation video: https://www.youtube.com/watch?v=pzRfw71XhFM
- New License manager
- Size and Parameters window with more board
and rider description fields
- New Board Selector that can replace
the Windows file browser
- Protection or unprotection of a complete folder
from the Board Selector
- New Stock Wizard
- Wood plan plan rail or Bead and cove
- Scan Import option improvements
- Display slices aligned on bot stringer, lower point
or real height
- Align control points horizontally or vertically
- New Measure arc depth function
- Zig-zag down moves for Bull Nose stringer cut in CNC
Login
to obtain the DOWNLOAD link
Version 9.1.1.2 (29/09/2020)
- Presentation video: https://www.youtube.com/watch?v=T8xgWL41P4c
- Correction of the freezing on CATALINA Mac OS
- Resize V/Concave with thickness, rocker or none
- Plug fixed to center or rail, tail or nose for resize
- Plug label positioning for the print sheet
- Nose tail symmetry for 3D layers
- Possibility to change the type of a 3D layer
- Flex approximation computation
- Drag approximation computation (adaptation of John Winter's KAPER algorithm for kayaks)
- CNC cut with definition of number of rail paths or rail narrowing
- Use of reference curve for clean CNC cut of boards with wings
- And alot of miscellaneous improvements
and corrections!
Login
to obtain the DOWNLOAD link
Version 9.1.1.0 (10/03/2020)
- New installer for CATALINA Mac OS!
!WARNING! There is still a problem we didn’t solve yet: if you click on the top bar of the main window of Shape3d it makes Shape3d freeze. But we found a work around: just move the main window and it’ll unlock Shape3d.
- New concave/V resize modes
- More plugs functionalities
- Show plugs and 3D layers in file browser
- Obj export with artworks
- Stringer roughing for 3D layers
- Possibility to move board in auto-blank, and export the auto-blank
- And alot of miscellaneous improvements
and corrections!
Login
to obtain the DOWNLOAD link
Version 9.1.0.6 (04/10/2019)
- Correction for non-Retina Mac. Sorry guys!
- And a few other corrections.
!WARNING! for Mac users:
The Mac installer is for Mojave or Sierra High only!
Don't download this update if you're using an older OS version!
Also we don't have an installer for the Catalina OS yet!
So don't update your OS to Catalina until next update in a couple of weeks!
Login
to obtain the DOWNLOAD link
Version 9.1.0.5 (01/10/2019)
!WARNING! for Mac users:
The Mac installer is for Mojave or Sierra High only!
Don't download this update if you're using an older OS version!
Also we don't have an installer for the Catalina OS yet!
So don't update your OS to Catalina until next update in a couple of weeks!
Updates:
- 3D layers with Smooth edges option
- Extend/reduce function on 3D layers
- Plugs with position fixed to another plug
- Selection of multiple plugs
- Allow defining plugs and points position from center
- Production sheet with deck/bot/side views from 3D
- Colorband shifted and straight mode
- IGES export with closed tail and nose and swallow tail
- Swallow tail cut option in CNC mode
- And alot of miscellaneous improvements
and corrections!
Login
to obtain the DOWNLOAD link
Version 9.1.0.4 (14/12/2018)
- New installer for Mac Mojave and Retina screen
(Don't update if your OS is older than 10.13.0)
- Enlarge windows and font option
- Orthogonal curvature display
- Symmetric slices for twin tip boards or foils
- Slices edited on Deck or Bottom only
- ID Numbers show main geometric properties
- Hydrostatic stability curves in Plan mode
- Rotate guidelines
- Map your own image on plugs in 3D
- CNC Table mode with definition of block dimensions
- CNC Mold mode
- Progressive curvature speed mode
- And alot of miscellaneous improvements
and corrections!
Login
to obtain the DOWNLOAD link
Version 9.1.0.2 (05/02/2018)
- Miscellaneous improvements
and corrections from version 9.1.0.1:
- Asymmetric board option,
also allows designing fins and foil wings
- Better managing of multiple files opening
- Better importation of brd files
- Corrections for Mac Sierra High
- CNC 3D layers Roughing
- New plugs cutting system
- New Hot Wire cut system
- Automatic EPS block blank system
and bed type CNC machine
- CNC outline path with swallow tail
...
